Lee's Summit

Code Statement

All issues pertaining to life safety and property protection from the hazards of fire, explosion or dangerous conditions in new and existing buildings, structures and premises, and to the safety to fire fighters and emergency responders during emergency operations, shall be in accordance with the 2018 International Fire Code.

Misc.

Provide No Parking signage per the Traffic Review.

Misc.

Knox Boxes are not required on this project.

DE C&O #01 Eng Plans – FP/PP

All required engineering plans and studies, including water lines, sanitary sewers, storm drainage, streets and erosion and sediment control shall be submitted along with the final plat and approved prior to the approval of the final plat. All public infrastructure must be substantially complete, prior to the issuance of any building permits.

DE C&O #02 Master Drainage Plan

A Master Drainage Plan (MDP) shall be submitted and approved in accordance with the City’s Design and Construction Manual for all areas of the development, including all surrounding impacted areas, along with the engineering plans for the development.

DE C&O #03 Eng & Insp Fees

All Engineering Plan Review and Inspection Fees shall be paid prior to approval of the associated engineering plans and prior to the issuance of any infrastructure permits or the start of construction (excluding land disturbance permit).

DE C&O #04 Cert FA or Escrow

All subdivision-related public improvements must have a Certificate of Final Acceptance prior to approval of the final plat, unless security is provided in the manner set forth in the City's Unified Development Ordinance (UDO). If security is provided, building permits may be issued upon issuance of a Certificate of Substantial Completion of the public infrastructure as outlined in Section 1000 of the City's Design and Construction Manual.

DE C&O #05 As-Graded MDP

The As-graded Master Drainage Plan shall be submitted to and accepted by the City prior to the issuance of a Certificate of Substantial Completion and prior to the issuance of any building permits for the development.

DE C&O #06 Land Disturbance

A Land Disturbance Permit shall be obtained from the City if ground breaking will take place prior to the issuance of an infrastructure permit, building permit, or prior to the approval of the Final Development Plan / Engineering Plans.

DE C&O #07 Easements

All permanent off-site easements, in a form acceptable to the City, shall be executed and recorded with the Jackson County Recorder of Deeds prior to the approval of the engineering plans or approval of the final plat. A certified copy shall be submitted to the City for verification.

DE C&O #08 Changes to MDP

A restriction note shall be included on the final plat stating: “Individual lot owner(s) shall not change or obstruct the drainage flow paths on the lots, as shown on the Master Drainage Plan, unless specific application is made and approved by the City Engineer."

DE C&O #12 Cut & Fill

Any cut and / or fill operations, which cause public infrastructure to exceed the maximum / minimum depths of cover shall be mitigated by relocating the infrastructure vertically and / or horizontally to meet the specifications contained within the City’s Design and Construction Manual.

DE C&O #13 ADA Sidewalk Ramps

All ADA sidewalk ramps shall be constructed by the developer at the time the street is constructed.

DE C&O #14 Common Area Sidewalks

All sidewalks adjacent to a common area tract, unplatted land or any land where no structure is intended to be built, and is required, shall be constructed by the developer at the time the street is constructed.

In considering a preliminary development plan application, the Planning Commission and City Council will give consideration to certain criteria. Specifically, the extent to which the proposed use will negatively affect the aesthetics of the neighboring property and the character of the neighborhood. Please articulate how the proposed development fits with the existing neighborhood character. Additionally, please provide insight as to how this particular architectural style was selected given staffs previous guidance to ensure the proposed homes fit with the historical nature of the area.

The total number of cul-de-sac lots in a subdivision shall be no more than ten percent of the total number of lots in the subdivision. As proposed the total number of cul-de-sac lots in the development is 100%. Please add this modification request to your letter.

The architectural sheet lists the project name as Burton Duplex. Please update this to the current project title to avoid confusion.

Please provide an isometric rendering to help convey a better understanding of the proposed structure.

Please add the total acreage to the legal descriptions.

Please add total building height to the site data table.

All signs must comply with the sign requirements as outlined in the sign section of the ordinance. If you are going to request a modification plead add it to you modification request letter.

Remove the Fire Lane Markings proposed on the curb of this public street. Parking is prohibited in this area by ordinance considering the location and spacing of driveways. Fire Department recommends restricted parking along one side of the street to maintain emergency access considering the density proposed. No parking will be required on one side of the street (and cul-de-sac). Upon approval of the project and prior to substantial completion of road construction, staff will process necessary requirements to establish No Parking. Developer will be required to install No Parking signs, per City standards/specifications in coordination with the road construction and shall be shown on the Engineer Plan submittals. Developer's preference to which side of street is parking restricted may be reflected on the drawings at such time.

DE C&O #01 Eng Plans – FP/PP

All required engineering plans and studies, including water lines, sanitary sewers, storm drainage, streets and erosion and sediment control shall be submitted along with the final plat and approved prior to the approval of the final plat. All public infrastructure must be substantially complete, prior to the issuance of any building permits.

DE C&O #02 Master Drainage Plan

A Master Drainage Plan (MDP) shall be submitted and approved in accordance with the City’s Design and Construction Manual for all areas of the development, including all surrounding impacted areas, along with the engineering plans for the development.

DE C&O #03 Eng & Insp Fees

All Engineering Plan Review and Inspection Fees shall be paid prior to approval of the associated engineering plans and prior to the issuance of any infrastructure permits or the start of construction (excluding land disturbance permit).

DE C&O #04 Cert FA or Escrow

All subdivision-related public improvements must have a Certificate of Final Acceptance prior to approval of the final plat, unless security is provided in the manner set forth in the City's Unified Development Ordinance (UDO). If security is provided, building permits may be issued upon issuance of a Certificate of Substantial Completion of the public infrastructure as outlined in Section 1000 of the City's Design and Construction Manual.

DE C&O #05 As-Graded MDP

The As-graded Master Drainage Plan shall be submitted to and accepted by the City prior to the issuance of a Certificate of Substantial Completion and prior to the issuance of any building permits for the development.

DE C&O #06 Land Disturbance

A Land Disturbance Permit shall be obtained from the City if ground breaking will take place prior to the issuance of an infrastructure permit, building permit, or prior to the approval of the Final Development Plan / Engineering Plans.

DE C&O #07 Easements

All permanent off-site easements, in a form acceptable to the City, shall be executed and recorded with the Jackson County Recorder of Deeds prior to the approval of the engineering plans or approval of the final plat. A certified copy shall be submitted to the City for verification.

DE C&O #08 Changes to MDP

A restriction note shall be included on the final plat stating: “Individual lot owner(s) shall not change or obstruct the drainage flow paths on the lots, as shown on the Master Drainage Plan, unless specific application is made and approved by the City Engineer."

DE C&O #12 Cut & Fill

Any cut and / or fill operations, which cause public infrastructure to exceed the maximum / minimum depths of cover shall be mitigated by relocating the infrastructure vertically and / or horizontally to meet the specifications contained within the City’s Design and Construction Manual.

DE C&O #13 ADA Sidewalk Ramps

All ADA sidewalk ramps shall be constructed by the developer at the time the street is constructed.

DE C&O #14 Common Area Sidewalks

All sidewalks adjacent to a common area tract, unplatted land or any land where no structure is intended to be built, and is required, shall be constructed by the developer at the time the street is constructed.

Code Statement

All issues pertaining to life safety and property protection from the hazards of fire, explosion or dangerous conditions in new and existing buildings, structures and premises, and to the safety to fire fighters and emergency responders during emergency operations, shall be in accordance with the 2018 International Fire Code.

Misc.

Provide a street name.

Misc.

Provide No Parking signage per the Traffic Review.

Misc.

Knox Boxes are not required on this project.

Density related modifications to current zoning or changes to zoning for residental uses require compliance with Unimproved Road Policy.

Consider a road alignment for the Extension of Orchard with a horizontal (185'-200') radius that eliminates the partial bulb between the cul-de-sac and Olive.

Identify areas where on-street or off-street parking can be accommodated or proposed (outside driveways/garages), if any, for guest and overflow parking.

Please provide a copy of the legal description in a Word format.

Please label the width of the proposed sidewalks.

Please label the building setback lines from streets with dimensions.

In considering a preliminary development plan application, the Planning Commission and City Council will give consideration to certain criteria. Specifically, the extent to which the proposed use will negatively affect the aesthetics of the neighboring property and the character of the neighborhood. Please articulate how the proposed development fits with the existing neighborhood character. Additionally, please provide insight as to how this particular architectural style was selected given staffs previous guidance to ensure the proposed homes fit with the historical nature of the area.

The proposed footprints on sheet C03 don’t seem to be consistent with the footprints show on the architectural sheet. Please update the all sheets so that they are consistent and accurate.

As shown, buildings 4, 7, and 12 are violating the 20’ front yard setback. The modification request letter dated December 11, 2019 states only one building is proposed to not meet the required setback. Staff is unlikely to support this request.

The proposed elevations show the 2nd floor overhanging into the side yards significantly. Please dash in this overhang on the site plan.

In the site data table please include the total number of proposed units, and list the dwelling units per acre, with and without common area.

Is the existing home at 502 NW Orchard remaining? Is it is, it must be included in the units/acre calculations.

The total number of cul-de-sac lots in a subdivision shall be no more than ten percent of the total number of lots in the subdivision. As proposed the total number of cul-de-sac lots in the development is 100%. This will require a modification. Cul-de-sacs shall be no longer than 500 feet and the maximum number of dwelling units on a cul-de-sac shall be 20. As proposed you will have 36 units. This will require a modification as well.

On sheet L01, it is unclear where the proposed buffer fence will be located. Additionally, if you wish to locate the fence on or near the property line a modification will be required.

FYI, an approved plat will be required prior the issuance of building permits.

The architectural sheet still lists the project name as Burton Townhouse. Please update this to the current project title to avoid confusion.

The street network is shown as public. As such, water lines should be shown as public. No backflow vault should be shown if this is a public street.

The grading plan does not address drainage to the south of buildings 12 and 13. Please shown the proposed and finish grading, and ensure there is no adverse impact to adjacent property owners.

The grading plan shown in Burton Townhowmes application does not match the grading plan shown in this most recent proposal. In particular, the grading to the north of Buildings 1, 2 and 3 originally showed a swale on the Burton Townhome application, whereas this application shows no such swale. Is the existing home at 502 NW Olive St. going to remain "as-is"? If so, why is it being shown as part of this development? It appears to be included within the limits of this project.

A public sanitary sewer extension is shown between Building 3 and 4 with too little distance between them. Minimum distance between any portion of the buildings, and the outside of the sanitary sewer line, is fifteen (15) feet. This would include any overhangs on the buildings, footings, etc.

Public sanitary sewer manholes are shown terminating in the middle of cul-de-sac bulbs, which is not allowed under the current Design and Construction Manual.

The public sanitary sewer is too close to Building 5. In addition, it is also to close to the northwest corner of Building 4.

A monument sign is shown in what appears to be an easement. In addition, it is too close to a public water main. Minimum distance is ten (10) feet, as measured from the outside of the pipe, and any portion of the monument sign, including footings.

Where is the proposed right of way and proposed easements for the public street? A minimum of ten (10) feet of general utility easement is required adjacent to all public right of way.

Please show in graphic format, the maximum water surface elevation within the two detention basins. This would include the 100% clogged/zero available storage event. A minimum of 20 feet is required between this level, and any building or property line.

If the home at 502 NW Olive St. is a part of this project, please show the existing street access to Olive St. As shown, it does not appear to have any access. Our records indicate an existing driveway.

Code Statement

All issues pertaining to life safety and property protection from the hazards of fire, explosion or dangerous conditions in new and existing buildings, structures and premises, and to the safety to fire fighters and emergency responders during emergency operations, shall be in accordance with the 2018 International Fire Code.

Misc.

Provide a street name.
