Review Type |
Outcome |
Est. Completion Date |
Completed |
Sprinkler Plan Review
|
Released for Construction
|
05/02/2022
|
02/06/2023
|
|
Jim Eden
|
|
Construction documents - Fire protection systems
Corrective Action Required
2018 IFC 901.2- Construction documents. The fire code official shall have the authority to require construction documents and calculations for all fire protection systems and to require permits be issued for the installation, rehabilitation or modification of any fire protection system. Construction documents for fire protection systems shall be submitted for review and approval prior to system installation.
Stamped plans received 2/26/2023.
|
|
Installation acceptance testing
Corrective Action Required
2018 IFC 901.5- Installation acceptance testing. Fire detection and alarm systems, fire-extinguishing systems, fire hydrant systems, fire standpipe systems, fire pump systems, private fire service mains and all other fire protection systems and appurtenances thereto shall be subject to acceptance tests as contained in the installation standards and as approved by the fire code official. The fire code official shall be notified before any required acceptance testing. The fire code official shall be notified 48 hours before any required acceptance test.
Call (816) 969-1300 to schedule hydrostatic and flow tests.
|
|
Misc
Corrective Action Required
Where the sprinkler designer has located the FDC is acceptable. Make sure the exterior horn strobe and Knox box are located at the same place as the FDC.
If the alcoves qualify for coverage, leave it in. Complete dimensions were not provided for the SW alcove which appears to be larger than the NE, correct as needed.
|
|
Miscellaneous Correction
Corrective Action Required
Under Building Notes it has the building construction as II-B. The correct construction type is V-B.
|
|
|
Fire Plan Review
|
Approved with Conditions
|
02/02/2023
|
01/30/2023
|
|
Ben Hicks
|
|
Construction documents for fire alarm systems
Corrective Action Required
2018 IFC 907.1.1- Construction documents. Construction documents for fire alarm systems shall be submitted for review and approval prior to system installation. Construction documents shall include, but not be limited to, all of the following: 1. .A floor plan which indicates the use of all rooms. 2. Locations of alarm-initiating and notification appliances. 3. Alarm control and trouble signaling equipment. 4. Annunciation. 5. Power connection. 6. Battery calculations. 7. Conductor type and sizes. 8. Voltage drop calculations. 9. Manufacturers, model numbers and listing information for equipment, devices and materials. 10. Details of ceiling height and construction. 11. The interface of fire safety control functions.
Action required- Provide shop drawings for review and approval. It's understood alarm notification on the second floor will minimal.
|
|
Knox box required
2018 IFC 506.1- Where required. Where access to or within a structure or an area is restricted because of secured openings or where immediate access is necessary for life-saving or fire-fighting purposes, the fire code official is authorized to require a key box to be installed in an approved location. The key box shall be of an approved type and shall contain keys to gain necessary access as required by the fire code official.
Action required- A Knox box shalll be mounted 6' AFF over the FDC. Go to Knoxbox.com to order the box. Verified at inspection.
|
|
Construction documents - Fire protection systems
Corrective Action Required
2018 IFC 901.2- Construction documents. The fire code official shall have the authority to require construction documents and calculations for all fire protection systems and to require permits be issued for the installation, rehabilitation or modification of any fire protection system. Construction documents for fire protection systems shall be submitted for review and approval prior to system installation.
Action required- Provide shop drawings for review and approval.
|
|
Direction of swing
Corrective Action Required
2018 IFC 1010.1.2.1 Direction of swing. Doors shall swing in the direction of egress travel where serving a room or area containing an occupant load of 50 or more persons or a Group H occupancy.
Action required- The egress door on the southeast corner of the building shall swing outward. Verified at inspection
|
|
Installation acceptance testing
Corrective Action Required
2018 IFC 901.5- Installation acceptance testing. Fire detection and alarm systems, fire-extinguishing systems, fire hydrant systems, fire standpipe systems, fire pump systems, private fire service mains and all other fire protection systems and appurtenances thereto shall be subject to acceptance tests as contained in the installation standards and as approved by the fire code official. The fire code official shall be notified before any required acceptance testing. The fire code official shall be notified 48 hours before any required acceptance test.
Action Required: Call 816-969-1300 to schedule systems testing
|
|
|
Engineering Review
|
No Comments
|
02/02/2023
|
01/26/2023
|
|
Gene Williams, P.E.
|
|
Miscellaneous Correction
Corrective Action Required
PRCOM20221592
|
|
|
Engineering Review
|
Approved with Conditions
|
12/30/2022
|
12/30/2022
|
|
Gene Williams, P.E.
|
|
Miscellaneous Correction
Corrective Action Required
PRCOM20221592
|
|
|
Engineering Review
|
Rejected
|
12/28/2022
|
12/21/2022
|
|
Gene Williams, P.E.
|
|
Miscellaneous Correction
Corrective Action Required
PRCOM20221592
|
|
|
Fire Plan Review
|
Approved with Conditions
|
12/28/2022
|
12/21/2022
|
|
Jim Eden
|
|
Construction documents for fire alarm systems
Corrective Action Required
2018 IFC 907.1.1- Construction documents. Construction documents for fire alarm systems shall be submitted for review and approval prior to system installation. Construction documents shall include, but not be limited to, all of the following: 1. .A floor plan which indicates the use of all rooms. 2. Locations of alarm-initiating and notification appliances. 3. Alarm control and trouble signaling equipment. 4. Annunciation. 5. Power connection. 6. Battery calculations. 7. Conductor type and sizes. 8. Voltage drop calculations. 9. Manufacturers, model numbers and listing information for equipment, devices and materials. 10. Details of ceiling height and construction. 11. The interface of fire safety control functions.
Action required- Provide shop drawings for review and approval. It's understood alarm notification on the second floor will minimal, awaiting tenant finish plans.
|
|
Construction documents - Fire protection systems
Corrective Action Required
2018 IFC 901.2- Construction documents. The fire code official shall have the authority to require construction documents and calculations for all fire protection systems and to require permits be issued for the installation, rehabilitation or modification of any fire protection system. Construction documents for fire protection systems shall be submitted for review and approval prior to system installation.
Action required- Provide shop drawings for review and approval.
|
|
Direction of swing
Corrective Action Required
2018 IFC 1010.1.2.1 Direction of swing. Doors shall swing in the direction of egress travel where serving a room or area containing an occupant load of 50 or more persons or a Group H occupancy.
Action required- The egress door on the southeast corner of the building shall swing outward.
|
|
Knox box required
2018 IFC 506.1- Where required. Where access to or within a structure or an area is restricted because of secured openings or where immediate access is necessary for life-saving or fire-fighting purposes, the fire code official is authorized to require a key box to be installed in an approved location. The key box shall be of an approved type and shall contain keys to gain necessary access as required by the fire code official.
Action required- A Knox box shalll be mounted 6' AFF over the FDC. Go to Knoxbox.com to order the box. Verified at inspection.
|
|
|
Building Plan Review
|
Approved
|
12/28/2022
|
12/19/2022
|
|
Joe Frogge
|
|
|
Engineering Review
|
Rejected
|
10/11/2022
|
10/11/2022
|
|
Gene Williams, P.E.
|
|
Miscellaneous Correction
Corrective Action Required
PRCOM20221592
|
|
|
Zoning Review
|
Approved
|
09/20/2022
|
09/14/2022
|
|
Joe Frogge
|
|
|
Building Plan Review
|
Approved
|
09/20/2022
|
09/13/2022
|
|
Joe Frogge
|
|
|
Fire Plan Review
|
Approved with Conditions
|
10/04/2022
|
09/13/2022
|
|
Joe Frogge
|
|
Construction documents for fire alarm systems
2018 IFC 907.1.1- Construction documents. Construction documents for fire alarm systems shall be submitted for review and approval prior to system installation. Construction documents shall include, but not be limited to, all of the following: 1. .A floor plan which indicates the use of all rooms. 2. Locations of alarm-initiating and notification appliances. 3. Alarm control and trouble signaling equipment. 4. Annunciation. 5. Power connection. 6. Battery calculations. 7. Conductor type and sizes. 8. Voltage drop calculations. 9. Manufacturers, model numbers and listing information for equipment, devices and materials. 10. Details of ceiling height and construction. 11. The interface of fire safety control functions.
Action required- Provide shop drawings for review and approval.
|
|
Knox box required
2018 IFC 506.1- Where required. Where access to or within a structure or an area is restricted because of secured openings or where immediate access is necessary for life-saving or fire-fighting purposes, the fire code official is authorized to require a key box to be installed in an approved location. The key box shall be of an approved type and shall contain keys to gain necessary access as required by the fire code official.
|
|
Construction documents - Fire protection systems
2018 IFC 901.2- Construction documents. The fire code official shall have the authority to require construction documents and calculations for all fire protection systems and to require permits be issued for the installation, rehabilitation or modification of any fire protection system. Construction documents for fire protection systems shall be submitted for review and approval prior to system installation.
Action required- Provide shop drawings for review and approval.
|
|
Miscellaneous Correction
Show the location of the fire protection main and location of the backflow valve and FDC.
|
|
Direction of swing
2018 IFC 1010.1.2.1 Direction of swing. Doors shall swing in the direction of egress travel where serving a room or area containing an occupant load of 50 or more persons or a Group H occupancy.
Action required- Egress doors shall swing outward.
|
|
Miscellaneous Correction
903.2.1.2 Group A-2. An automatic sprinkler system
shall be provided throughout stories containing Group
A-2 occupancies and throughout all stories from the
Group A-2 occupancy to and including the levels of
exit discharge serving that occupancy where one of the
following conditions exists:
1. The fire area exceeds 5,000 square feet (464 m2).
2. The fire area has an occupant load of 100 or
more.
3. The fire area is located on a floor other than a
level of exit discharge serving such occupancies.
Action required- The proposed square footage for the separated A2 occupancy calculating 50% of the space as dining and 50% as kitchen, still has an occupant of greater than 100 and would require an automatic sprinkler system.
|
|
Miscellaneous Correction
Corrective Action Required
All of the above requirements are needed if a portion of the building is changed to an A2 use. The type of tenant has yet to be determined per the designer.
|
|
Construction documents for fire alarm systems
2018 IFC 907.1.1- Construction documents. Construction documents for fire alarm systems shall be submitted for review and approval prior to system installation. Construction documents shall include, but not be limited to, all of the following: 1. .A floor plan which indicates the use of all rooms. 2. Locations of alarm-initiating and notification appliances. 3. Alarm control and trouble signaling equipment. 4. Annunciation. 5. Power connection. 6. Battery calculations. 7. Conductor type and sizes. 8. Voltage drop calculations. 9. Manufacturers, model numbers and listing information for equipment, devices and materials. 10. Details of ceiling height and construction. 11. The interface of fire safety control functions.
Action required- Provide shop drawings for review and approval.
|
|
Knox box required
2018 IFC 506.1- Where required. Where access to or within a structure or an area is restricted because of secured openings or where immediate access is necessary for life-saving or fire-fighting purposes, the fire code official is authorized to require a key box to be installed in an approved location. The key box shall be of an approved type and shall contain keys to gain necessary access as required by the fire code official.
|
|
Construction documents - Fire protection systems
2018 IFC 901.2- Construction documents. The fire code official shall have the authority to require construction documents and calculations for all fire protection systems and to require permits be issued for the installation, rehabilitation or modification of any fire protection system. Construction documents for fire protection systems shall be submitted for review and approval prior to system installation.
Action required- Provide shop drawings for review and approval.
|
|
Miscellaneous Correction
Show the location of the fire protection main and location of the backflow valve and FDC.
|
|
Direction of swing
2018 IFC 1010.1.2.1 Direction of swing. Doors shall swing in the direction of egress travel where serving a room or area containing an occupant load of 50 or more persons or a Group H occupancy.
Action required- Egress doors shall swing outward.
|
|
Miscellaneous Correction
903.2.1.2 Group A-2. An automatic sprinkler system
shall be provided throughout stories containing Group
A-2 occupancies and throughout all stories from the
Group A-2 occupancy to and including the levels of
exit discharge serving that occupancy where one of the
following conditions exists:
1. The fire area exceeds 5,000 square feet (464 m2).
2. The fire area has an occupant load of 100 or
more.
3. The fire area is located on a floor other than a
level of exit discharge serving such occupancies.
Action required- The proposed square footage for the separated A2 occupancy calculating 50% of the space as dining and 50% as kitchen, still has an occupant of greater than 100 and would require an automatic sprinkler system.
|
|
Miscellaneous Correction
Corrective Action Required
All of the above requirements are needed if a portion of the building is changed to an A2 use. The type of tenant has yet to be determined per the designer.
|
|
|
Licensed Contractors
|
Approved
|
06/13/2022
|
06/27/2022
|
|
Joe Frogge
|
|
LC - MEP Subs
Lee's Summit Code of Ordinance, Section7-130.4 - Business License. (excerpt)
No person, other than a licensed contractor or employees of a licensed contractor, shall engage in electrical, plumbing or mechanical business, construction, installation or maintenance unless duly licensed in accordance with this section.
Action required: MEP subcontractors are required to be listed on permit. Provide company names of licensed MEP contractors.
5/24/22 - acknowledged in letter
|
|
LC - General Contractor
Lee's Summit Code of Ordinance, Section7-130.10 - Business License. It shall be unlawful for any person to engage in the construction contracting business without first obtaining a business license as required under the applicable provisions of Chapter 28 of the Lee's Summit Code of Ordinances.
Action required: Either a Class A or Class B license is required. Provide the company name of the licensed general contractor and an email address & phone number for the on-site contact which is where inspection reports will be sent.
5/24/22 - acknowledged in letter
|
|
|
Fire Plan Review
|
Approved with Conditions
|
06/13/2022
|
06/14/2022
|
|
Jim Eden
|
|
Construction documents for fire alarm systems
2018 IFC 907.1.1- Construction documents. Construction documents for fire alarm systems shall be submitted for review and approval prior to system installation. Construction documents shall include, but not be limited to, all of the following: 1. .A floor plan which indicates the use of all rooms. 2. Locations of alarm-initiating and notification appliances. 3. Alarm control and trouble signaling equipment. 4. Annunciation. 5. Power connection. 6. Battery calculations. 7. Conductor type and sizes. 8. Voltage drop calculations. 9. Manufacturers, model numbers and listing information for equipment, devices and materials. 10. Details of ceiling height and construction. 11. The interface of fire safety control functions.
Action required- Provide shop drawings for review and approval.
|
|
Knox box required
2018 IFC 506.1- Where required. Where access to or within a structure or an area is restricted because of secured openings or where immediate access is necessary for life-saving or fire-fighting purposes, the fire code official is authorized to require a key box to be installed in an approved location. The key box shall be of an approved type and shall contain keys to gain necessary access as required by the fire code official.
|
|
Construction documents - Fire protection systems
2018 IFC 901.2- Construction documents. The fire code official shall have the authority to require construction documents and calculations for all fire protection systems and to require permits be issued for the installation, rehabilitation or modification of any fire protection system. Construction documents for fire protection systems shall be submitted for review and approval prior to system installation.
Action required- Provide shop drawings for review and approval.
|
|
Miscellaneous Correction
Show the location of the fire protection main and location of the backflow valve and FDC.
|
|
Direction of swing
2018 IFC 1010.1.2.1 Direction of swing. Doors shall swing in the direction of egress travel where serving a room or area containing an occupant load of 50 or more persons or a Group H occupancy.
Action required- Egress doors shall swing outward.
|
|
Miscellaneous Correction
903.2.1.2 Group A-2. An automatic sprinkler system
shall be provided throughout stories containing Group
A-2 occupancies and throughout all stories from the
Group A-2 occupancy to and including the levels of
exit discharge serving that occupancy where one of the
following conditions exists:
1. The fire area exceeds 5,000 square feet (464 m2).
2. The fire area has an occupant load of 100 or
more.
3. The fire area is located on a floor other than a
level of exit discharge serving such occupancies.
Action required- The proposed square footage for the separated A2 occupancy calculating 50% of the space as dining and 50% as kitchen, still has an occupant of greater than 100 and would require an automatic sprinkler system.
|
|
Miscellaneous Correction
Corrective Action Required
All of the above requirements are needed if a portion of the building is changed to an A2 use. The type of tenant has yet to be determined per the designer.
|
|
|
Building Plan Review
|
Approved
|
06/13/2022
|
06/07/2022
|
|
Joe Frogge
|
|
|
Fire Plan Review
|
Rejected
|
06/02/2022
|
05/31/2022
|
|
Jim Eden
|
|
Address numbers required
2018 IFC 505.1- Address numbers. New and existing buildings shall have approved address numbers, building numbers or approved building identification placed in a position that is plainly legible and visible from the street or road fronting the property. These numbers shall contrast with their background. In Multi-tenant commercial building where tenants have multiple entrances located on different sides of the building , each door shall be addressed. Address numbers shall be Arabic numerals or alphabet letters. Numbers shall be a minimum of 4 inches (102 mm) high with a minimum stroke width of 0.5 inch (12.7 mm).
|
|
Knox box required
2018 IFC 506.1- Where required. Where access to or within a structure or an area is restricted because of secured openings or where immediate access is necessary for life-saving or fire-fighting purposes, the fire code official is authorized to require a key box to be installed in an approved location. The key box shall be of an approved type and shall contain keys to gain necessary access as required by the fire code official.
|
|
Construction documents for fire alarm systems
Corrective Action Required
2018 IFC 907.1.1- Construction documents. Construction documents for fire alarm systems shall be submitted for review and approval prior to system installation. Construction documents shall include, but not be limited to, all of the following: 1. .A floor plan which indicates the use of all rooms. 2. Locations of alarm-initiating and notification appliances. 3. Alarm control and trouble signaling equipment. 4. Annunciation. 5. Power connection. 6. Battery calculations. 7. Conductor type and sizes. 8. Voltage drop calculations. 9. Manufacturers, model numbers and listing information for equipment, devices and materials. 10. Details of ceiling height and construction. 11. The interface of fire safety control functions.
Action required- Provide shop drawings for review and approval.
|
|
Construction documents - Fire protection systems
Corrective Action Required
2018 IFC 901.2- Construction documents. The fire code official shall have the authority to require construction documents and calculations for all fire protection systems and to require permits be issued for the installation, rehabilitation or modification of any fire protection system. Construction documents for fire protection systems shall be submitted for review and approval prior to system installation.
Action required- Provide shop drawings for review and approval.
|
|
Miscellaneous Correction
Corrective Action Required
Show the location of the fire protection main and location of the backflow valve and FDC.
|
|
Direction of swing
Corrective Action Required
2018 IFC 1010.1.2.1 Direction of swing. Doors shall swing in the direction of egress travel where serving a room or area containing an occupant load of 50 or more persons or a Group H occupancy.
Action required- Egress doors shall swing outward.
|
|
Miscellaneous Correction
Corrective Action Required
903.2.1.2 Group A-2. An automatic sprinkler system
shall be provided throughout stories containing Group
A-2 occupancies and throughout all stories from the
Group A-2 occupancy to and including the levels of
exit discharge serving that occupancy where one of the
following conditions exists:
1. The fire area exceeds 5,000 square feet (464 m2).
2. The fire area has an occupant load of 100 or
more.
3. The fire area is located on a floor other than a
level of exit discharge serving such occupancies.
Action required- The proposed square footage for the separated A2 occupancy calculating 50% of the space as dining and 50% as kitchen, still has an occupant of greater than 100 and would require an automatic sprinkler system.
|
|
Miscellaneous Correction
Provide a remote emergency light head over the front exit of the first floor north space.
|
|
Miscellaneous Correction
Where will the basement access be located and what if any work will be done there?
|
|
|
Building Plan Review
|
Approved
|
06/02/2022
|
05/25/2022
|
|
Joe Frogge
|
|
IBC 1606.2 Design dead load - structural
2018 IBC 1606.2 Design dead load. For purposes of design, the actual weights of materials of construction and fixed service equipment shall be used. In the absence of definite information, values used shall be subject to the approval of the building official.
Action required: Provide verification that existing roof structure will support additional load at new RTUs. (new curbs shown on A101 but not reflected in Structural plans)
5/24/22 - per architect, load is addressed in S drawings
|
|
Misc
City of Lee's Summit Code of Ordinances Sec. 8.180. - Architectural characteristics.
G.Trash enclosures. All exterior trash storage containers shall be screened so that they are not visible from off the property.1.Each trash enclosure shall be constructed of masonry walls or steel architecturally designed walls with either a solid steel opaque gate painted to be compatible with the color of the masonry or steel walls and building it is to serve or a steel framed semi-opaque gate with a screen mesh material approved by the Director that provides an appropriate visual barrier.
Action required: Trash enclosure gates to be constructed of listed materials. (plans unclear as to exact materials of gate and screening)
|
|
IMC 602.1 Appliances in plenums
2018 IMC 602.1 General. Supply, return, exhaust, relief and ventilation air plenums shall be limited to uninhabited crawl spaces, areas above a ceiling or below the floor, attic spaces, mechanical equipment rooms and the framing cavities addressed in Section 602.3. Plenums shall be limited to one fire area. Air systems shall be ducted from the boundary of the fire area served directly to the air-handling equipment. Fuel-fired appliances shall not be installed within a plenum.
Action required: Comment is for informational purposes. Installation of gas fired furnaces above restrooms will restrict future hvac to ducted systems.
5/24/22 - acknowledged in letter
|
|
Misc
Coordinate required between Civil and MEP.
Action required: Civil drawings show 2 water services but MEP only shows 1. Coordinate and clarify.
|
|
IBC 1008.3 Emergency power for illumination - at exit discharge
2018 IBC 1008.3 Emergency power for illumination. The power supply for means of egress illumination shall normally be provided by the premises’ electrical supply.
1008.3.1 General. In the event of power supply failure in rooms and spaces that require two or more means of egress, an emergency electrical system shall automatically illuminate all of the following areas:
1. Aisles.
2. Corridors.
3. Exit access stairways and ramps.
1008.3.2 Buildings. In the event of power supply failure in buildings that require two or more means of egress, an emergency electrical system shall automatically illuminate all of the following areas:
1. Interior exit access stairways and ramps.
2. Interior and exterior exit stairways and ramps.
3. Exit passageways.
4. Vestibules and areas on the level of discharge used for exit discharge in accordance with Section 1028.1.
5. Exterior landings as required by Section 1010.1.6 for exit doorways that lead directly to the exit discharge.
Action required: Provide emergency lighting at exterior side of all exits. (one missing at northeast exit)
|
|
|
Licensed Contractors
|
Rejected
|
06/02/2022
|
05/25/2022
|
|
Joe Frogge
|
|
LC - MEP Subs
Corrective Action Required
Lee's Summit Code of Ordinance, Section7-130.4 - Business License. (excerpt)
No person, other than a licensed contractor or employees of a licensed contractor, shall engage in electrical, plumbing or mechanical business, construction, installation or maintenance unless duly licensed in accordance with this section.
Action required: MEP subcontractors are required to be listed on permit. Provide company names of licensed MEP contractors.
5/24/22 - acknowledged in letter
|
|
LC - General Contractor
Corrective Action Required
Lee's Summit Code of Ordinance, Section7-130.10 - Business License. It shall be unlawful for any person to engage in the construction contracting business without first obtaining a business license as required under the applicable provisions of Chapter 28 of the Lee's Summit Code of Ordinances.
Action required: Either a Class A or Class B license is required. Provide the company name of the licensed general contractor and an email address & phone number for the on-site contact which is where inspection reports will be sent.
5/24/22 - acknowledged in letter
|
|
|
Fire Plan Review
|
Rejected
|
05/02/2022
|
05/02/2022
|
|
Jim Eden
|
|
Construction documents for fire alarm systems
Corrective Action Required
2018 IFC 907.1.1- Construction documents. Construction documents for fire alarm systems shall be submitted for review and approval prior to system installation. Construction documents shall include, but not be limited to, all of the following: 1. .A floor plan which indicates the use of all rooms. 2. Locations of alarm-initiating and notification appliances. 3. Alarm control and trouble signaling equipment. 4. Annunciation. 5. Power connection. 6. Battery calculations. 7. Conductor type and sizes. 8. Voltage drop calculations. 9. Manufacturers, model numbers and listing information for equipment, devices and materials. 10. Details of ceiling height and construction. 11. The interface of fire safety control functions.
Action required- Provide shop drawings for review and approval.
|
|
Address numbers required
Corrective Action Required
2018 IFC 505.1- Address numbers. New and existing buildings shall have approved address numbers, building numbers or approved building identification placed in a position that is plainly legible and visible from the street or road fronting the property. These numbers shall contrast with their background. In Multi-tenant commercial building where tenants have multiple entrances located on different sides of the building , each door shall be addressed. Address numbers shall be Arabic numerals or alphabet letters. Numbers shall be a minimum of 4 inches (102 mm) high with a minimum stroke width of 0.5 inch (12.7 mm).
|
|
Knox box required
Corrective Action Required
2018 IFC 506.1- Where required. Where access to or within a structure or an area is restricted because of secured openings or where immediate access is necessary for life-saving or fire-fighting purposes, the fire code official is authorized to require a key box to be installed in an approved location. The key box shall be of an approved type and shall contain keys to gain necessary access as required by the fire code official.
|
|
Construction documents - Fire protection systems
Corrective Action Required
2018 IFC 901.2- Construction documents. The fire code official shall have the authority to require construction documents and calculations for all fire protection systems and to require permits be issued for the installation, rehabilitation or modification of any fire protection system. Construction documents for fire protection systems shall be submitted for review and approval prior to system installation.
Action required- Provide shop drawings for review and approval.
|
|
Miscellaneous Correction
Corrective Action Required
Show the location of the fire protection main and location of the backflow valve and FDC.
|
|
Direction of swing
Corrective Action Required
2018 IFC 1010.1.2.1 Direction of swing. Doors shall swing in the direction of egress travel where serving a room or area containing an occupant load of 50 or more persons or a Group H occupancy.
Action required- Egress doors shall swing outward.
|
|
Miscellaneous Correction
Corrective Action Required
Provide a remote emergency light head over the front exit of the first floor north space.
|
|
Miscellaneous Correction
Corrective Action Required
Where will the basement access be located and what, if any work will be done there?
|
|
|
Building Plan Review
|
Rejected
|
05/02/2022
|
04/28/2022
|
|
Joe Frogge
|
|
IBC 1606.2 Design dead load - structural
Corrective Action Required
2018 IBC 1606.2 Design dead load. For purposes of design, the actual weights of materials of construction and fixed service equipment shall be used. In the absence of definite information, values used shall be subject to the approval of the building official.
Action required: Provide verification that existing roof structure will support additional load at new RTUs. (new curbs shown on A101 but not reflected in Structural plans)
|
|
Misc
Corrective Action Required
City of Lee's Summit Code of Ordinances Sec. 8.180. - Architectural characteristics.
G.Trash enclosures. All exterior trash storage containers shall be screened so that they are not visible from off the property.1.Each trash enclosure shall be constructed of masonry walls or steel architecturally designed walls with either a solid steel opaque gate painted to be compatible with the color of the masonry or steel walls and building it is to serve or a steel framed semi-opaque gate with a screen mesh material approved by the Director that provides an appropriate visual barrier.
Action required: Trash enclosure gates to be constructed of listed materials. (plans unclear as to exact materials of gate and screening)
|
|
IMC 602.1 Appliances in plenums
Corrective Action Required
2018 IMC 602.1 General. Supply, return, exhaust, relief and ventilation air plenums shall be limited to uninhabited crawl spaces, areas above a ceiling or below the floor, attic spaces, mechanical equipment rooms and the framing cavities addressed in Section 602.3. Plenums shall be limited to one fire area. Air systems shall be ducted from the boundary of the fire area served directly to the air-handling equipment. Fuel-fired appliances shall not be installed within a plenum.
Action required: Comment is for informational purposes. Installation of gas fired furnaces above restrooms will restrict future hvac to ducted systems.
|
|
Misc
Corrective Action Required
Coordinate required between Civil and MEP.
Action required: Civil drawings show 2 water services but MEP only shows 1. Coordinate and clarify.
|
|
IBC 1008.3 Emergency power for illumination - at exit discharge
Corrective Action Required
2018 IBC 1008.3 Emergency power for illumination. The power supply for means of egress illumination shall normally be provided by the premises’ electrical supply.
1008.3.1 General. In the event of power supply failure in rooms and spaces that require two or more means of egress, an emergency electrical system shall automatically illuminate all of the following areas:
1. Aisles.
2. Corridors.
3. Exit access stairways and ramps.
1008.3.2 Buildings. In the event of power supply failure in buildings that require two or more means of egress, an emergency electrical system shall automatically illuminate all of the following areas:
1. Interior exit access stairways and ramps.
2. Interior and exterior exit stairways and ramps.
3. Exit passageways.
4. Vestibules and areas on the level of discharge used for exit discharge in accordance with Section 1028.1.
5. Exterior landings as required by Section 1010.1.6 for exit doorways that lead directly to the exit discharge.
Action required: Provide emergency lighting at exterior side of all exits. (one missing at northeast exit)
|
|
|
Engineering Review
|
Approved
|
04/27/2022
|
04/27/2022
|
|
Gene Williams, P.E.
|
|
|
Licensed Contractors
|
Rejected
|
05/02/2022
|
04/27/2022
|
|
Joe Frogge
|
|
LC - MEP Subs
Corrective Action Required
Lee's Summit Code of Ordinance, Section7-130.4 - Business License. (excerpt)
No person, other than a licensed contractor or employees of a licensed contractor, shall engage in electrical, plumbing or mechanical business, construction, installation or maintenance unless duly licensed in accordance with this section.
Action required: MEP subcontractors are required to be listed on permit. Provide company names of licensed MEP contractors.
|
|
LC - General Contractor
Corrective Action Required
Lee's Summit Code of Ordinance, Section7-130.10 - Business License. It shall be unlawful for any person to engage in the construction contracting business without first obtaining a business license as required under the applicable provisions of Chapter 28 of the Lee's Summit Code of Ordinances.
Action required: Either a Class A or Class B license is required. Provide the company name of the licensed general contractor and an email address & phone number for the on-site contact which is where inspection reports will be sent.
|
|
|
